Yttrium Vanadate(YVO4) is a positive uniaxial crystal grown with Czochralski method. It has good temperature stability and physical and mechanical properties. It is ideal for optical polarizing components because of its wide transparency range and large birefringence. It is an excellent synthetic substitute for Calcite (CaCO3) and Rutile (TiO2) crystals in many applications including fiber optic isolators and circulators, interleavers, beam displacers and other polarizing optics.
Description:
1. High electro-optic conversion efficiency.
2. Low power consumption, stability laser output.
3. High quality beam, consumable free, small machine dimension.
4. Smaller output laser beam,finer marking line. Suitable high precision marking.
5. User friendly software interface, easy operation.
|
Product Name |
Fiber Laser Marking Machine |
|
Model |
FLFB20 |
|
Output Power |
20W(Optional) |
|
Pulse Repetition Rate |
1-400KHZ |
|
Laser Module |
JPT(Optional) |
|
Galvo |
SINO-TECH/ Customized |
|
Lens |
Sino tech |
|
Beam Quality |
<1.2 |
|
Software |
2.14.10 version |
|
Two Axis Function |
Opened |
|
Buttons |
Imported from Taiwan |
|
Power Supply |
Taiwan |
|
Wires |
CCC certificated |
|
Cables |
CE certificated |
|
Key switch |
CE certificated |
|
Red Light Positioning |
Yes |
|
Monitor Arm |
Yes |
|
Led Lamp |
Yes |
|
Cooling Method |
Air cooling |
|
Life Span |
100,000 hours |
|
Gross Power |
600W |
|
Operating Voltage |
AC 110V/220V 50/60HZ 5A |
|
Laser Wavelength |
1064nm |
|
Engraving Range |
100×100mm、175*175mm （Optional for other size） |
|
Repetition Precision |
±0.003mm |
|
Engraving Speed |
≤8000mm/s |
|
Minimum Line Width |
0.01mm |
|
Character Size |
0.5-110mm |
|
Cooling System |
Air Cooling |
|
Cable Length |
3m （5m optional） |
|
Working Temperature Range |
10-30℃ |
|
Working Humidity |
20%-80% |
|
Net Weight of machine |
100kg |
Our products have been widely applied to electrical appliances, handsets, hardware, precision machinery, jewelries, glasses, clocks, watches, craft work gifts, plastic mold, medical instruments,etc. Maintains good relations of cooperation with many famous international laser companies and famous experts in laser field. Sincerely provide customers with full range of laser solutions.
We care about what you need and create the product what you want. We always firmly believe that a professional attitude creates a better life. “The best sales is service, the best brand is reputation.”
